Piusi|F0040700A
PIUSI K24 Digital Flow Meter 7-120lpm F0040700A
Tax excluded. Shipping calculated at checkout
GST (10%) is calculated at checkout. Tax invoices provided with all orders.
Contact for live availability
Our inventory signal hasn't refreshed today. We update twice daily but the latest reading is stale.
Email sales@goind.com.au or call 07 3204 2240 for live availability.
Ships from Brisbane warehouse. Standard delivery 2-5 business days Australia-wide.
ACCURATE DIESEL METERING WITHOUT THE PREMIUM PRICE TAG
Piusi K24 electronic flow meter, DN25 (1 BSP female), 100 bar rated. Aluminium body, 120 L/min throughput. Direct-read digital display for diesel dispensing.
What you get
The K24 gives you an electronic display and 120 L/min flow in a half-kilo aluminium body. DN25 BSP female threads drop into most diesel dispensing setups without adapters. 100 bar pressure rating means it won't choke typical transfer pump outputs. You see litres dispensed per fill on the screen, reset between jobs, and move on.
Who this suits
Workshop fuel points, farm bulk tanks, service truck installs. Sites that need to track usage without logging every transaction to a backend system. If you want totaliser memory or batch control, step up to the K44 or K600. The K24 does the core job: measure the pour, show the number, repeat.
Features & Benefits
Key Features
- Electronic display, litres per fill
- Flow capacity 120 L/min
- DN25 (1 BSP female) threads
- 100 bar pressure rating
- Aluminium body
- 0.5 kg weight, easy to handle
- Diesel duty
Benefits
- Know exactly how much fuel went in each time
- Fits standard 1 BSP plumbing, quick swap-in
- Light enough to mount inline without extra support
- 100 bar rating handles typical pump output pressures
| Flow Rate | 7-120lpm |
| Accuracy | +/- 1% |
| Repeatability | 0.2% |
| Max Working Pressure | 10 Bar (150PSI) |
| Display Running | 5 Digit 0.1 to 99999 |
| Display Totaliser | 6 Digit 1 to 999999 |
| Dimensions | 112.5mm L x 75mm W x 60.5mm H |
| Weight | 0.5kg |
| Includes | DN25 (1") Socket to facilitate DN25 (1") MF BSP Inlet and Outlet |
| Pressure Drop | 0.03 Bar |
| Batteries | 2 x AAA (included) |
| 4 options for volume measurement | Quarts (Qts), |
| Able to operate in one of two dispensing modes | Normal - the meter will display the Running and Totaliser Volumes dispensed |
Shipping & Dimensions
Ships from Brisbane warehouse. Standard delivery 2-5 business days.
Downloads
Compare
Compare Similar Products
7-120lpm
19 to 114 L/min
20-120 l/min
+/- 1%
± 2.0% of reading (Accuracy is factory calibrated using diesel fuel)
—
0.2%
± 0.5%
—
10 Bar (150PSI)
—
—
5 Digit 0.1 to 99999
—
—
6 Digit 1 to 999999
—
—
112.5mm L x 75mm W x 60.5mm H
—
—
0.5kg
—
1.9
DN25 (1") Socket to facilitate DN25 (1") MF BSP Inlet and Outlet
—
—
0.03 Bar
—
—
2 x AAA (included)
—
—
Quarts (Qts),
—
—
Normal - the meter will display the Running and Totaliser Volumes dispensed
—
—
Compatible Products
Frequently Asked Questions
Can't find your answer?
Contact UsWhat is the Piusi K24 meter?
An electronic flow meter with digital display that measures diesel throughput up to 120 L/min. DN25 (1 BSP female) connections, 100 bar rated, aluminium body.
What thread size does it use?
DN25, which is 1 BSP female. Fits standard Australian diesel plumbing.
Can I use this for petrol or other fuels?
Spec sheet lists diesel only. For other fluids, contact sales@goind.com.au to confirm seal and calibration compatibility.
Does it have a totaliser or just per-fill display?
The K24 shows litres per dispense on the digital readout. For totaliser or batch control, step up to the K44 or K600 models.
What warranty and support do I get?
12 months on defects. Rotating elements and seals are consumables. For fitment or bulk orders, call 07 3204 2240 or email sales@goind.com.au.
