Graco|204254
GRACO Fire-Ball 300 5:1 Oil Pumps
Tax excluded. Shipping calculated at checkout
GST (10%) is calculated at checkout. Tax invoices provided with all orders.
Contact for live availability
Our inventory signal hasn't refreshed today. We update twice daily but the latest reading is stale.
Email sales@goind.com.au or call 07 3204 2240 for live availability.
Ships from Brisbane warehouse. Standard delivery 2-5 business days Australia-wide.
WORKSHOP DRUM DISPENSING WITHOUT THE ELECTRIC HOOKUP
5:1 air-operated piston pump for 55-gallon drums. Designed for medium-viscosity fluids, including lubricants and light oils, in workshop and mobile service applications.
Air-powered simplicity
The Fireball 300 runs off your shop compressor. No electric motor to spark near flammables, no flex to run, no switchboard hassles. Drop it on a drum bung, connect the air line, and you're dispensing. When the drum's empty, lift it off and drop it on the next one.
Medium-viscosity workhorse
This pump handles hydraulic oils, transmission fluids, and lighter lubricants. It's not built for thick gear oils or greases, and it doesn't pretend to be. For most workshop and service-truck lube jobs, the 5:1 ratio delivers the flow you need without burning through air or overloading seals.
Features & Benefits
Key Features
- 5:1 air-operated piston pump
- Bung-mounted for 55-gallon drums
- Handles medium-viscosity lubricants and oils
- 13 kg unit weight
- No electrical connection required
- Piston pump design
- Portable between drums and service trucks
- Workshop compressor compatible
Benefits
- Plug into existing shop air, no wiring
- Swap between drums in seconds
- Keeps dispensing as drum empties
- Safer than electric pumps around flammables
- Light enough for one person to handle
| Max Working Pressure | 900 |
| Maximum Intermittent Cycle Rate (CPM) | 70 |
| Maximum Air Consumption (SCFM) | 25 |
| Maximum Air Inlet Pressure (bar) | 12.41 |
| Maximum Air Inlet Pressure (psi) | 180 |
| Maximum Continuous Cycle Rate (CPM) | 70 |
| Air Inlet Size | 3/8 |
| Fluid Outlet Size | 12.7 |
| Fluid Outlet Thread | Female |
| Air Inlet Size (mm) | 9.525 |
| Air Inlet Thread Gender | Female |
| Fluid Inlet Size (in) | 1-1/2 |
| Fluid Inlet Size (mm) | 38.1 |
| Fluid Inlet Thread Gender | Female |
Shipping & Dimensions
Ships from Brisbane warehouse. Standard delivery 2-5 business days.
Downloads
Compare
Compare Similar Products
900
—
—
70
—
—
25
—
—
12.41
—
—
180
—
—
70
—
—
3/8
—
—
12.7
—
—
Female
—
—
9.525
—
—
Female
—
—
1-1/2
—
—
38.1
—
—
Female
—
—
Compatible Products
Frequently Asked Questions
Can't find your answer?
Contact UsWhat is the Graco Fireball 300 pump?
It's a 5:1 air-operated piston pump that mounts on the bung of a 55-gallon drum to dispense medium-viscosity lubricants, hydraulic oils, and transmission fluids.
What air pressure does it need?
The pump operates on standard workshop compressed air. Consult the manual for recommended pressure settings based on fluid viscosity and desired flow rate.
Can it handle heavy gear oils or greases?
The Fireball 300 is suited to medium-viscosity fluids. For heavy gear oils or greases, a higher-ratio pump may be required. Contact sales@goind.com.au for fluid compatibility advice.
Does it include hose and dispensing hardware?
The pump is sold as the base unit. Hose, reels, and nozzles are ordered separately to match your setup. We can quote complete systems.
What warranty and support comes with it?
12-month warranty on manufacturing defects. Seals and packings are wear items. For service support or replacement parts, contact sales@goind.com.au or 07 3204 2240.
