Graco|24G489
GRACO PLATE, BASE, 7 SECTION, MSP NPSF 24G489
Tax excluded. Shipping calculated at checkout
GST (10%) is calculated at checkout. Tax invoices provided with all orders.
Contact for live availability
Our inventory signal hasn't refreshed today. We update twice daily but the latest reading is stale.
Email sales@goind.com.au or call 07 3204 2240 for live availability.
Ships from Brisbane warehouse. Standard delivery 2-5 business days Australia-wide.
OEM BASE PLATE FOR GRACO MSP 7-SECTION METERING PUMPS
7-section NPSF base plate for Graco MSP pumps. Direct OEM replacement part, weighs 2.72 kg, secures pump sections in multi-ratio metering setups.
What it does
This base plate mounts and aligns a 7-section Graco MSP pump stack. Each section meters a different fluid ratio, common in epoxy coating and adhesive dispensing where you need precise multi-component mixing. The NPSF thread configuration provides a dry seal without thread tape.
When you need it
You are replacing a cracked or worn base plate on an existing MSP pump, or assembling a new multi-section stack for a coating or adhesive project. OEM fit means no shimming, no adaptation, no second-guessing thread engagement.
Features & Benefits
Key Features
- 7-section base plate configuration
- NPSF thread type
- Weight 2.72 kg
- Direct Graco MSP pump fit
- OEM replacement part
- Multi-ratio metering compatibility
Benefits
- Keeps multi-section pump stacks aligned and secure
- OEM part fits without adaptation or guesswork
- Restores full pump capacity when base wears or cracks
- Supports epoxy and coating dispensing workflows
| Max Working Pressure | 241 |
| Inlet Size | 1/4 |
| Outlet Size | 0.3175 |
| Weight | 2.72 |
| Divider Valve Series | MSP |
Shipping & Dimensions
Ships from Brisbane warehouse. Standard delivery 2-5 business days.
Downloads
Compatible Products
Frequently Asked Questions
Can't find your answer?
Contact UsWhat is the GRACO PLATE, BASE, 7 SECTION, MSP NPSF?
It is the OEM base mounting plate for Graco MSP multi-section metering pumps. It secures and aligns a 7-section pump stack used in epoxy, coating, and adhesive dispensing systems.
What does 7-section mean?
The base plate accommodates seven individual pump sections stacked together, allowing multi-ratio metering of different fluid components in a single assembly.
Is this compatible with non-Graco pumps?
No. This is an OEM Graco part designed specifically for MSP series pumps. Using it on other brands will not provide correct alignment or thread engagement.
What is NPSF threading?
National Pipe Straight Fuel thread. A dry-seal thread standard common in fluid handling. Requires no thread sealant when used with compatible fittings.
What warranty and support apply?
12-month manufacturer warranty covers material and casting defects. Installation damage such as cross-threading or impact cracks is not covered. For technical support or bulk orders, contact sales@goind.com.au or 07 3204 2240.
