Graco Husky 515 PVDF 12.7 mm (1/2 in.) BSP Standard Pump, PP Centre Section, PVDF Seats, PTFE Balls & PTFE Diaphragm · D5EA11
Tax excluded. Shipping calculated at checkout
GST (10%) is calculated at checkout. Tax invoices provided with all orders.
Contact for live availability
Our inventory signal hasn't refreshed today. We update twice daily but the latest reading is stale.
Email sales@goind.com.au or call 07 3204 2240 for live availability.
Ships from Brisbane warehouse. Standard delivery 2-5 business days Australia-wide.
GRACO HUSKY 515 PVDF UP TO 57 L/MIN
Graco Husky 515 air-operated double diaphragm pump, up to 57 L/min. Air-driven fluid transfer for chemical, fuel and process duties with no electric drive required.
Wetted parts matched to your chemistry
Air-operated double diaphragm pumps live or die on the wetted-path materials. This configuration is built around the body, seats, balls and diaphragm material listed in the specifications, so it stands up to the fluids it is rated for and not the cheap-and-cheerful list.
Runs off shop air, anywhere on site
Pneumatic operation means no motor, no priming circuit, no electrical hookup. Self-priming, dry-run safe and serviceable in the field. Stall-free air valve, minimal pulsation, runs from up to 100 psi air supply.
Features & Benefits
Key Features
- 1/2" fluid ports.
- Up to 57 L/min continuous flow.
- Stall-free air valve, minimal pulsation, runs off compressed shop air with no electric drive.
- Self-priming and dry-run safe, serviceable in the field without specialist tooling.
| Maximum Air Pressure (bar) | 7 |
| Maximum Flow Rate (L/min) | 57 |
| Maximum Fluid Pressure (bar) | 7 |
| Maximum Air Pressure (psi) | 100 |
| Maximum Fluid Pressure (psi) | 100 |
| Air Exhaust Port Size (in) | 3/8 |
| Air Inlet Size (in) | 1/4 |
| Fluid Outlet Thread Gender | Female |
| Fluid Outlet Size (mm) | 12.7 |
| Fluid Inlet Thread Gender | Female |
| Fluid Inlet Size (mm) | 12.7 |
| Fluid Inlet Size (in) | 1/2 |
| Maximum Solid Size (cm) | 0.2383 |
| Maximum Solid Size (in) | 0.09375 |
| Maximum Solid Size (mm) | 2.4 |
| Air Inlet Thread Gender | Female |
| Air Exhaust Port Thread Gender | Female |
| Maximum Air Consumption (SCFM) | 28 |
| Maximum Operating Temperature (°C) | 104 |
| Maximum Operating Temperature (°F) | 220 |
| Minimum Operating Temperature (°C) | 4 |
| Minimum Operating Temperature (°F) | 40 |
| compressor_required | Yes |
| Maximum Cycle Rate (CPM) | 400 |
