GRACO HUSKY 515 POLYPROPYLENE UP TO 57 L/MIN
Graco Husky 515 air-operated double diaphragm pump, polypropylene construction, PTFE/EPDM 2-Piece diaphragms, 1/2" ports, up to 57 L/min. Air-driven fluid transfer for chemical, fuel and process duties with no electric drive required.
PTFE/EPDM 2-Piece diaphragms in a polypropylene fluid section
Air-operated double diaphragm pumps live or die on the wetted-path materials. This configuration is built around the body, seats, balls and diaphragm material listed in the specifications, so it stands up to the fluids it is rated for and not the cheap-and-cheerful list.
Runs off shop air, anywhere on site
Pneumatic operation means no motor, no priming circuit, no electrical hookup. Self-priming, dry-run safe and serviceable in the field. Stall-free air valve, minimal pulsation, runs from up to 100 psi air supply.
Features & Benefits
Key Features
- Polypropylene fluid section with PTFE/EPDM 2-Piece diaphragms.
- Polypropylene seats and PTFE check balls.
- 1/2" NPT fluid inlet and outlet, 1/4" air inlet.
- Up to 57 L/min continuous flow.
- Stall-free air valve, minimal pulsation, runs off compressed shop air with no electric drive.
- Self-priming and dry-run safe, serviceable in the field without specialist tooling.
| Maximum Air Pressure (psi) | 100 |
| Maximum Flow Rate (gpm) | 15 |
| Maximum Fluid Pressure (psi) | 100 |
| Maximum Air Pressure (bar) | 7 |
| Maximum Flow Rate (l/min) | 57 |
| Maximum Fluid Pressure (bar) | 7 |
| Air Exhaust Port Size (in) | 3/8 |
| Air Inlet Size (in) | 1/4 |
| Air Inlet Thread Gender | Female |
| Air Inlet Thread Type | NPT |
| Ball Material | PTFE |
| Centre Section Material | Polypropylene |
| Diaphragm Compatible Material | PTFE |
| Diaphragm Material | PTFE/EPDM 2-Piece |
| Fluid Inlet Size (in) | 1/2 |
| Fluid Inlet Thread Gender | Female |
| Fluid Inlet Thread Type | NPT |
| Fluid Outlet Size (in) | 1/2 |
| Fluid Outlet Thread Gender | Female |
| Fluid Outlet Thread Type | NPT |
| Fluid Section Material | Polypropylene |
| Manifold Configuration | Centre Port |
| Manifold O-Ring Material | PTFE |
| Material | Polypropylene |
| Maximum Solid Size (in) | 0.09375 |
| Seat Material | Polypropylene |
| Weight (lb) | 6.5 |
| Wetted Material | Polypropylene, PTFE/EPDM |
| Fluid Inlet Size (mm) | 12.7 |
| Fluid Outlet Size (mm) | 12.7 |
| Maximum Solid Size (cm) | 0.2383 |
| Maximum Solid Size (mm) | 2.4 |
| Power Source | Air |
| Air Exhaust Port Thread Type | NPT |
| Air Inlet Thread Type | NPT |
| Fluid Inlet Thread Type | NPT |
| Fluid Outlet Thread Type | NPT |
| Standards Met | ATEX, CE |
| Type | Pneumatic Diaphragm Pump |
| Air Exhaust Port Thread Gender | Female |
| Maximum Air Consumption (SCFM) | 28 |
| Maximum Cycle Rate (cpm) | 400 |
| Maximum Operating Temperature (°F) | 150 |
| Minimum Operating Temperature (°F) | 40 |
| Maximum Operating Temperature (°C) | 66 |
| Minimum Operating Temperature (°C) | 4 |
