Graco|965129
GRACO Fire-Ball 425 10:1 Grease Pumps 965129
Tax excluded. Shipping calculated at checkout
GST (10%) is calculated at checkout. Tax invoices provided with all orders.
Contact for live availability
Our inventory signal hasn't refreshed today. We update twice daily but the latest reading is stale.
Email sales@goind.com.au or call 07 3204 2240 for live availability.
Ships from Brisbane warehouse. Standard delivery 2-5 business days Australia-wide.
PROVEN 10:1 PNEUMATIC PUMP FOR GREASE AND OIL AT A FAIR PRICE
10:1 ratio air-powered pump for mid-viscosity greases and oils, delivering reliable high-pressure transfer in workshop and mobile service applications.
Air-powered reliability
The Fireball 425 runs on your existing compressed air supply, eliminating the need for electrical infrastructure or spark-risk management. Air motors are simple, durable, and easy to service in the field. At 19 kg, the unit is light enough to relocate between bays or mount on a mobile service truck without heavy lifting gear.
Handles most greases
The 10:1 pressure ratio suits the mid-viscosity greases and oils used across fleet maintenance, production lubrication, and general workshop tasks. You are not chasing specialised pumps for every fluid. Field-serviceable components mean seals and valves can be swapped on-site when wear occurs, keeping downtime short.
Features & Benefits
Key Features
- 10:1 pressure ratio
- Air-powered operation
- 19 kg unit weight
- Handles greases and mid-viscosity oils
- Field-serviceable design
- Suitable for mobile and fixed installations
Benefits
- No electric supply needed, works off shop air
- Covers most greases without pump swaps
- Light enough to move between bays or trucks
- Parts available when seals or valves need replacing
| Maximum Air Inlet Pressure (bar) | 12.41 |
| Maximum Air Inlet Pressure (psi) | 180 |
| Maximum Flow Rate (L/min) | 13.25 |
| Maximum Intermittent Cycle Rate (CPM) | 60 |
| Maximum Continuous Cycle Rate (CPM) | 60 |
| Max Working Pressure | 124 |
| Air Inlet Size | 0.5 |
| Fluid Outlet Size | 25.4 |
| Fluid Outlet Thread | Female |
| Air Motor Effective Diameter (in) | 4.25 |
| Air Inlet Thread Gender | Female |
| Air Inlet Size (mm) | 12.7 |
Shipping & Dimensions
Ships from Brisbane warehouse. Standard delivery 2-5 business days.
Downloads
Compare
Compare Similar Products
12.41
10.34
—
180
150
—
13.25
1.89
—
60
—
—
60
—
—
124
7500
5000
0.5
0.5
0.25
25.4
9.525
6.35
Female
Female
—
4.25
—
—
Female
Female
—
12.7
12.7
—
Compatible Products
Frequently Asked Questions
Can't find your answer?
Contact UsWhat is the Graco Fireball 425 pump?
A 10:1 ratio pneumatic pump for transferring greases and mid-viscosity oils in workshop and mobile service applications. Runs on compressed air, weighs 19 kg.
What fluids can it handle?
Mid-viscosity greases and oils commonly used in fleet and production maintenance. Not suited for very heavy greases or low-viscosity solvents.
Does it need an electric supply?
No. The pump runs entirely on compressed air, making it safe for use in areas where electric spark risk is a concern.
Can I mount it on a mobile service rig?
Yes. At 19 kg and with no electrical requirement, it suits mobile installations on service trucks or trolleys.
What warranty and support apply?
12-month warranty on manufacturing defects. Wear components are consumables and excluded. For parts, service, or installation queries, contact sales@goind.com.au or 07 3204 2240.
