Flomec|EB406D0FM
FLOMEC EB40 Single-Stage Batch Controller
Tax excluded. Shipping calculated at checkout
All prices are in AUD and exclude GST.
GST (10%) is calculated at checkout. Tax invoices provided with all orders.
GST (10%) is calculated at checkout. Tax invoices provided with all orders.
Contact for live availability
Our inventory signal hasn't refreshed today. We update twice daily but the latest reading is stale.
Email sales@goind.com.au or call 07 3204 2240 for live availability.
Ships from Brisbane warehouse. Standard delivery 2-5 business days Australia-wide.
Free Shipping $500+
12 Month Warranty
AU Stock
FLOMEC EB40 Single-Stage Batch Controller
Sale price$584.00
About the FLOMEC EB40 Single-Stage Batch Controller
QUALITY FLUID HANDLING EQUIPMENT FOR AUSTRALIAN INDUSTRY
FLOMEC EB40 single-stage batch controller with 10 recipe storage, self-learning overrun correction, and IP66/67 weather-resistant enclosure. Compatible with reed switch, NPN, VR coil, and Weigand flow meter sensors. Available in field mount or meter mount with GRN or aluminium housing options.
Housing Material
Glass Reinforced Nylon (PA6) or Powder Coated Aluminium
Lens
Polycarbonate protective lens
Gasket
Santoprene
IP Rating (GRN)
IP66/67 - NEMA4X
IP Rating (Aluminium)
IP65 - NEMA4X
View all
Industrial Grade
PURPOSE-BUILT FOR FUEL HANDLING
Quality batch controller from GO Industrial, built for Australian conditions.
Built to Last
QUALITY THAT STANDS UP TO THE JOB
Backed by GO Industrial's technical support team and 12-month manufacturer warranty. Contact sales@goind.com.au or 07 3204 2240.
12mo
manufacturer
warranty included
warranty included
Features & Benefits
Key Features
- Store up to 10 frequently used batch recipes for quick recall via batch memory table
- Non-linear correction for accurate measurements across a wide flow range
- Self-learning overrun correction prevents costly product waste and overruns
- Optional batch interlock prevents operation without a receiving vessel present
- Built-in diagnostics simplify installation, commissioning, and troubleshooting
- Automatic no signal detection ensures flow meter or wiring failure does not result in uncontrolled batching
- Bright backlit 6-digit LCD display with count up and count down function
- FLOMEC CDS software compatible for PC-based configuration and diagnostics via USB
- Auto backup retains all settings, recipes, and accumulated totals after power loss
- Compatible with reed switch, NPN hall effect, VR coil, and Weigand flow meter sensors
Physical
| Housing Material | Glass Reinforced Nylon (PA6) or Powder Coated Aluminium |
| Lens | Polycarbonate protective lens |
| Gasket | Santoprene |
| IP Rating (GRN) | IP66/67 - NEMA4X |
| IP Rating (Aluminium) | IP65 - NEMA4X |
| Dimensions (W x H x D) | 114.3mm x 66mm x 99mm |
| Operating Temperature | -30 to +80 degrees C |
Housing Material
Glass Reinforced Nylon (PA6) or Powder Coated Aluminium
Lens
Polycarbonate protective lens
Gasket
Santoprene
IP Rating (GRN)
IP66/67 - NEMA4X
IP Rating (Aluminium)
IP65 - NEMA4X
Dimensions (W x H x D)
114.3mm x 66mm x 99mm
Operating Temperature
-30 to +80 degrees C
Compliance
| Certifications | CE, NEMA4, IP66/67 |
| Warranty | 2 years |
Certifications
CE, NEMA4, IP66/67
Warranty
2 years
Display and Interface
| Display Type | Dual line LCD |
| Top Line | 6 characters x 17mm high |
| Bottom Line | 8 characters x 7mm high |
| Backlight | LED backlight (requires external DC power) |
| Interface | 4-button intuitive operation |
| Recipe Storage | 10 batch memory slots |
| Count Mode | Count up from zero or count down from batch preset |
| Engineering Units | Litres, Cubic Metres, US/Imperial Gallons, Quarts, Fluid Ounces, Cubic Feet, Barrels, Millilitres, Kilograms, Pounds, or Custom |
Display Type
Dual line LCD
Top Line
6 characters x 17mm high
Bottom Line
8 characters x 7mm high
Backlight
LED backlight (requires external DC power)
Interface
4-button intuitive operation
Recipe Storage
10 batch memory slots
Count Mode
Count up from zero or count down from batch preset
Engineering Units
Litres, Cubic Metres, US/Imperial Gallons, Quarts, Fluid Ounces, Cubic Feet, Barrels, Millilitres, Kilograms, Pounds, or Custom
Power
| External DC Power | 12V - 30V DC regulated, 100mA typical |
| Battery Backup | AA (14505) 3.6V Lithium Thionyl Chloride - 10 year expected life |
| Sensor Power | 12V regulated supply (with external DC power applied) |
External DC Power
12V - 30V DC regulated, 100mA typical
Battery Backup
AA (14505) 3.6V Lithium Thionyl Chloride - 10 year expected life
Sensor Power
12V regulated supply (with external DC power applied)
Input and Output
| Flow Meter Input | Pulse/frequency input compatible with most flow meters |
| Reed Switch | 120Hz maximum |
| NPN Hall Effect | 2kHz maximum |
| VR Coil (Turbine) | 2kHz maximum |
| Weigand Sensors | 2kHz maximum, 15mV pk-pk minimum |
| Digital Output (Standard) | NPN open collector (sinking), 30V DC / 1A maximum |
| Relay Output (Optional) | Mechanical relay, 30V DC / 5A maximum |
| Safety Interlock | Normally open (NO) dry contact, switch, or reed switch |
| External Switch Inputs | 4x momentary NO switch inputs for remote operation |
| Electrical Entries | 3 entries - M16 x 1.5 conduit thread |
Flow Meter Input
Pulse/frequency input compatible with most flow meters
Reed Switch
120Hz maximum
NPN Hall Effect
2kHz maximum
VR Coil (Turbine)
2kHz maximum
Weigand Sensors
2kHz maximum, 15mV pk-pk minimum
Digital Output (Standard)
NPN open collector (sinking), 30V DC / 1A maximum
Relay Output (Optional)
Mechanical relay, 30V DC / 5A maximum
Safety Interlock
Normally open (NO) dry contact, switch, or reed switch
External Switch Inputs
4x momentary NO switch inputs for remote operation
Electrical Entries
3 entries - M16 x 1.5 conduit thread
Standards and Approvals
| FCC | 47CFR 15:2024 - Radio Frequency Devices |
| ICES | ICES-003: 2020 Issue 7 - IT Equipment EMC |
| ENIEC | 61326-1:2021 - Measurement and Control Equipment EMC |
FCC
47CFR 15:2024 - Radio Frequency Devices
ICES
ICES-003: 2020 Issue 7 - IT Equipment EMC
ENIEC
61326-1:2021 - Measurement and Control Equipment EMC
Shipping & Dimensions
0.5 kg
Weight
200 mm
Length
150 mm
Width
120 mm
Height
Ships from Brisbane warehouse. Standard delivery 2-5 business days Australia-wide.
Downloads
Frequently Asked Questions
Can't find your answer?
Contact UsWho manufactures the FLOMEC EB40 Single-Stage Batch Controller?
The FLOMEC EB40 Single-Stage Batch Controller is manufactured by FLOMEC and distributed by GO Industrial in Australia.
Does the FLOMEC EB40 Single-Stage Batch Controller come with a warranty?
Yes, all GO Fill products are covered by a manufacturer's warranty. Contact our team at sales@goind.com.au or 07 3204 2240 for warranty details.
