Graco|24T114
Graco XD70 Bare Reel 1" x 30m Oil, Yellow 24T114
Tax excluded. Shipping calculated at checkout
GST (10%) is calculated at checkout. Tax invoices provided with all orders.
Contact for live availability
Our inventory signal hasn't refreshed today. We update twice daily but the latest reading is stale.
Email sales@goind.com.au or call 07 3204 2240 for live availability.
Ships from Brisbane warehouse. Standard delivery 2-5 business days Australia-wide.
EXTREME DUTY SPRING REEL FOR WORKSHOPS THAT RUN HARD
Heavy-duty spring rewind hose reel for diesel and oil transfer, rated for extreme duty cycle. Supplied bare (no hose), NPT connections, 53 kg powder-coated steel frame.
Built for cycle count
Graco's XD rating isn't marketing fluff. This reel is all-steel, powder-coated, and designed for depots or workshops where a hose gets pulled and retracted dozens of times a day. The spring mechanism handles the load; the swivel inlet prevents kink at the base. At 53 kg, it's not a portable unit. It's anchored kit for fixed installations.
Bare reel, your choice
Sold without hose so you spec what suits: diesel-rated rubber, chemical hose for DEF, or high-pressure hydraulic line. This flexibility matters when one site needs 15 metres and another needs 30, or when you're matching existing hose stock across a fleet. NPT threads suit imported pumps and nozzles without adapters.
Features & Benefits
Key Features
- Spring rewind mechanism
- XD (extreme duty) rated construction
- Bare reel (hose sold separately)
- NPT threaded swivel inlet
- Yellow powder-coated steel frame
- 53.5 kg all-steel build
- High-visibility finish
- Suits diesel, oil, DEF transfer
Benefits
- Auto-retract keeps hose off the floor between jobs
- Heavy frame stands up to workshop traffic and weather
- Spec your own hose length and type to match the job
- NPT threads fit imported pumps and nozzles direct
- High-vis yellow easy to spot in cluttered bays
| Max Working Pressure | 3000 |
| Inlet Thread | Female |
| Inlet Size | 25.4 |
| Outlet Size | 1 |
| Outlet Thread | Female |
| Thread Type | NPT |
| Weight | 87 |
| Reel Type | Bare Reel |
| Frame Type | Box Frame |
| Fluid Compatibility | Oil |
| Maximum Temperature (°F) | 180 |
| Maximum Temperature (°C) | 82 |
| Minimum Temperature (°C) | -40 |
| Minimum Temperature (°F) | -40 |
Shipping & Dimensions
Ships from Brisbane warehouse. Standard delivery 2-5 business days.
Downloads
Compatible Products
Frequently Asked Questions
Can't find your answer?
Contact UsWhat is the Graco XD Series 70 reel?
A heavy-duty spring rewind hose reel for diesel, oil, or DEF transfer. Supplied bare (no hose) with NPT connections, rated for extreme duty cycle in workshops and depots.
Why is this reel sold without hose?
Bare reels let you choose hose material, diameter, and length to suit your exact application. Diesel, hydraulic oil, and DEF each need different hose specs.
What does XD (extreme duty) mean?
Graco's XD rating indicates the reel is built for continuous use in high-cycle environments like busy workshops, not occasional light-duty applications.
Will this reel take BSP fittings?
No, this model has NPT threads. If your site runs BSP plumbing, contact sales@goind.com.au for a BSP-threaded alternative or adapter options.
What warranty and support do I get?
12-month manufacturer warranty covers defects; wear parts like the spring are serviceable but not warranty items. For technical support or parts, contact sales@goind.com.au or 07 3204 2240.
